Cable Glands


IP 68 Cable Glands

Specification:

Item Brass IP68 Universal Cable Gland

Technical Information Material
Body with Lock Nuts Nickel Plated Brass
Insert Polyamide - 6
Sealing RIng Neoprene
O - Ring Perbunan

Additional Features :

• With Vibration Lock and Strain Relief Protection Class IP 68 - 5 Bar

• Temperature Range : -3000 to +9000 C



Technical Data:

Size Clamping Range Thread Length (in mm)
PG-7 2-6.50 6.00
PG-9 3-8.00 6.00
PG-11 4-10.00 6.00
PG-13.5 5-12.00 8.00
PG-16 8-14.00 8.00
PG-21 11-18.00 8.00
PG-29 16-25.00 9.00
PG-36 20-30.00 9.00
PG-42 28-38.00 12.00
PG-48 34-44.00 12.00
M12 2-6.50 6.00
M16 3-8.00 6.00
M20 5-12.00 8.00
M25 11-18.00 8.00
M32 12-21.00 8.00
M40 18-27.00 9.00
M50 27-33.00 9.00
M63 34-48.00 12.00

Cable Glands are suitable for connections provides with flexible cables in:

  • Weather Proof Enclosures
  • Control Panels
  • Limit Switches
  • Multi Pin Connectors
  • Controlling & Liquid Measuring Instrument
  • Machineries
  • Medical Equipments
  • Electric Motors

We manufacture other types of Accessories also and according to specifications, drawing and samples. Other Accessories like Cable Ties, Reducers, Enlargers, Adaptors, Converters, Stopping Plugs.
