Cable Glands
| Application: Brass | Brass Locknuts re traditional components used in fastening glands to the gland plate & as they are identical material to the gland, corrosion effects are minimal. |
| Function: Standard | With ISO metric thread. To secure only brass cable glands to a gland plate |
| EMC | With ISO metric thread with cutting edges to cut through paint layers or powder coatings, for optimum contact. |
| Material | Brass BS 2874 CZ121 Pb3 Steel, Galvanized Aluminium Alloy (BS 1476) |
| Options | |
| Thread | ET NPT BSP BSPT PG |
| Plating | Chrome (CP) Nickel (NP) Tin (TP) |
Brass Earth Tags
| Application | Installed between the gland entry & equipment, provides an earth bond connection |
| Function | Produces an earth bond connection for electrical continuity |
| Material | Brass BS 2870 CZ123 lead |
| Options | |
| Type | With Brass Screws & Washers, Plain Hole |
| Plating | Nickel (NP) Chrome (CP) Zinc (ZP) Tin (TP) |
| Material | Brass |
| Shape | Available in many shapes & thickness in all sizes, can be coated or plated to customers specification as mentioned. |
Hexagonal Reducers & Stop Plugs
| Application | Reducer allows a PG threaded gland to be terminated in enclosures with different entry thread form (ET NPT BSP BSPT) |
| Function | Reduce the entry thread diameter of enclosures |
| Material | Brass BS 2874 CZ121 Pb3 |
| Finish | Electro Nickel Plated |
| Options | |
| Thread | Metric (ISO) ET NPT BSP BSPT |
| Plating | Chrome (CP) Zinc (ZP) Tin (TP) |
| Material | Brass Casting BS 2874 Aluminium Alloy & Galvanized Steel |
| Application | Stop Plug may be used to close thread entries or means of sealing & stopping unused thread entries in flame proof enclosures |
| Ingress Protection | IP66 (with Nickel Thread Seal) IP368 (3 bar-with Nitrite 'O' Rings) |
| Options Thread | ET NPT BSP BSPT & PG |
PVS Shrouds
| Application | Push on shrouds which are used to minimize the risk of dirt or foreign substances gathering on the Cable Gland Body, and/or point of cable to a gland interface. |
| Function | For all types of gland applications to provide additional protection & enhances the IP rating of the gland termination. |
| Material | PVC DIP moulded (Black) |
| Operating Temp | PVC DIP moulded -200 C to +1000 C |
| Injection moulded -200 C to +800 C |
Star Washer
| Application | The serrated lock washer with external teeth for cable glands |
| Material | Available in Brass & Stainless Steel & Steel |
| Size | From M 20 to M 63 |
| Can be developed as per the drawing also | |
Seals & 'O' Rings
| Application | To maintain the IP rating between equipment & cable glands it may be necessary to fit an entry thread sealing washer at the gland entry interface. |
| Material | Nitrite Rubber & EPDM |
| Options Material | PVC (Black) Silicon (Orange) Polyamide or Nylon (White) Red Fibre. |
| Seals available for both external of & internal use. | |
